Coronary Artery Variation Phenotypes and Associated Clinical Characteristics in a Libyan Adult Cohort: A Multicentre Imaging Analysis

Authors: Yaseen Ahmad Muhammad Wafi; Emad M.N. Abdelwahab; Lubna Shirin; Mohammed S. Kabir
Coronary Artery Variation Phenotypes and Associated Clinical Characteristics in a Libyan Adult Cohort: A Multicentre Imaging Analysis
DOI
10.25125/imjh-sep-2026-2
DIN
IMJH-SEP-2026-2
Abstract

Background: Coronary artery variations encompass a heterogeneous group of developmental and morphological phenotypes whose clinical expression may differ according to subtype and patient characteristics. Population-specific data from North Africa remain limited.

Methods: This multicentre retrospective cross-sectional study analysed 200 Libyan adults aged 26–85 years who underwent coronary assessment at three referral centres. Coronary artery variation status and phenotype were abstracted from coronary imaging reports together with demographic, anthropometric, cardiovascular risk, and symptom data. Descriptive statistics, chi-square tests, Monte Carlo procedures for sparse contingency tables, Cramér's V, and one-way analysis of variance were used as appropriate.

Results: Coronary artery variations were identified in 87/200 participants (43.5%). Among variation-positive cases, anomalous origin/ostial variants were most frequent (33/87, 37.9%), followed by other/unspecified patterns (17.2%), branching/length variants (14.9%), ectasia/aneurysm (13.8%), myocardial bridging (10.3%), and interarterial/intramural courses (5.7%). Phenotype distribution differed by sex (Monte Carlo p=0.004), whereas no significant association was observed with age band (Monte Carlo p=0.243). Palpitations occurred more frequently in participants with a coronary variation than in those without one (19.5% vs 8.8%; χ²=4.811, p=0.028; V=0.155), although the effect size was small. Mean body mass index did not differ across variation phenotypes (F(5,81)=0.483, p=0.788).

Conclusion: Coronary artery variation phenotypes were common in this clinically referred Libyan cohort and showed distinct sex-related patterns and a modest association with palpitations. Phenotype-level anatomical reporting may add clinically useful information beyond recording the presence or absence of a coronary variation.

Keywords
coronary artery variations; coronary anomalies; coronary anatomy; Libya; coronary imaging; myocardial bridging; palpitations.
Download Options
Download Full PDF
Share Article
Facebook Twitter LinkedIn
Introduction

Coronary artery variations and anomalies comprise deviations in coronary origin, ostial position, course, branching, length, termination, or vessel morphology, and are commonly classified according to anatomical subtype to aid clinical and imaging interpretation [1,2]. Many are incidental, but selected phenotypes can influence myocardial perfusion, complicate catheter engagement or surgery, and alter procedural planning. Contemporary guidelines therefore emphasize accurate anatomical definition when a clinically relevant anomalous origin or course is suspected [3,4].

Reported prevalence varies markedly according to the population studied, imaging modality, and—critically—the definition used. Large angiographic and CT-based series restricted to congenital anomalies of origin and course generally report prevalence in the low single digits [5,6], whereas broader frameworks that include myocardial bridging, ectasia, branching patterns, and other coronary variants yield substantially higher estimates [7–10]. This definitional heterogeneity makes direct comparison between populations difficult and supports reporting individual phenotypes rather than a single pooled anomaly rate.

Coronary CT angiography (CCTA) provides three-dimensional assessment of coronary origin and course and is particularly useful for defining relationships with the aorta and pulmonary artery. Invasive coronary angiography remains central to the assessment and treatment of obstructive coronary disease but may be less informative for some three-dimensional anatomical relationships [3,4,11]. The increasing use of coronary imaging has consequently expanded recognition of anatomical phenotypes that were previously under-reported.

Evidence describing coronary variation phenotypes in North African populations is limited [12]. The present analysis was designed to characterise the phenotype distribution of coronary artery variations in a multicentre Libyan adult cohort and to examine selected demographic and clinical correlates. To maintain a distinct clinical-anatomical focus, the primary analyses address phenotype, sex, age, body mass index (BMI), and palpitations rather than comparative diagnostic performance between imaging modalities or multivariable prediction of coronary artery disease.

Medical Journal IMJ Health Call for Papers

Conclusion

Coronary artery variations were frequently documented in this clinically referred Libyan adult cohort, with anomalous origin/ostial patterns forming the largest phenotype group. Variation phenotype differed by sex but not significantly by age band, and palpitations were more common among participants with a documented variation. These findings support phenotype-level reporting of coronary anatomy and careful integration of anatomical findings with the patient's clinical presentation.

Larger prospective, sex-balanced studies using standardised coronary variation definitions are needed to establish population-specific prevalence and clinical risk. Future research should also address the limitations identified in this study, particularly the need for standardised imaging protocols, complete anatomical characterisation, and systematic symptom assessment.

References
  1. Kim, S. Y., Seo, J. B., Do, K. H., Heo, J. N., Lee, J. S., Song, J. W., et al. (2006). Coronary artery anomalies: Classification and ECG-gated multi-detector row CT findings with angiographic correlation. RadioGraphics, 26(2), 317-333. https://doi.org/10.1148/rg.262055068
  2. Beecham, R., Prater, S., & Batlle, J. (2026). Coronary artery anomalies. In StatPearls. StatPearls Publishing.
  3. Gurvitz, M., Krieger, E. V., Fuller, S., et al. (2026). 2025 ACC/AHA/HRS/ISACHD/SCAI guideline for the management of adults with congenital heart disease: A report of the American College of Cardiology/American Heart Association Joint Committee on Clinical Practice Guidelines. Journal of the American College of Cardiology, 87(7), 822-976. https://doi.org/10.1016/j.jacc.2025.09.006
  4. Stout, K. K., Daniels, C. J., Aboulhosn, J. A., et al. (2019). 2018 AHA/ACC guideline for the management of adults with congenital heart disease. Journal of the American College of Cardiology, 73(12), e81-e192. https://doi.org/10.1016/j.jacc.2018.08.1029
  5. Yamanaka, O., & Hobbs, R. E. (1990). Coronary artery anomalies in 126,595 patients undergoing coronary arteriography. Catheterization and Cardiovascular Diagnosis, 21(1), 28-40. https://doi.org/10.1002/ccd.1810210110
  6. Angelini, P., Velasco, J. A., & Flamm, S. (2002). Coronary anomalies: Incidence, pathophysiology, and clinical relevance. Circulation, 105(20), 2449-2454. https://doi.org/10.1161/01.CIR.0000016175.49835.57
  7. Graidis, C., Dimitriadis, D., Karasavvidis, V., Dimitriadis, G., Argyropoulou, E., Economou, F., et al. (2015). Prevalence and characteristics of coronary artery anomalies in an adult population undergoing multidetector-row computed tomography for the evaluation of coronary artery disease. BMC Cardiovascular Disorders, 15, 112. https://doi.org/10.1186/s12872-015-0098-x
  8. Ghadri, J. R., Kazakauskaite, E., Braunschweig, S., et al. (2014). Congenital coronary anomalies detected by coronary computed tomography compared to invasive coronary angiography. BMC Cardiovascular Disorders, 14, 81. https://doi.org/10.1186/1471-2261-14-81
  9. Ganga, K. P., Goyal, A., Ojha, V., Deepti, S., Sharma, S., & Kumar, S. (2021). Prevalence rates of congenital coronary anomalies and coronary variations in adult Indian population using dual-source computed tomography coronary angiography: Analysis of regional distribution of coronary anomalies and the need for standardized reporting formats. Indian Journal of Radiology and Imaging, 31(1), 138-149. https://doi.org/10.1055/s-0041-1730135
  10. Al-Balas, H., Mouhsen, A. M., Ababneh, G. E., Alkhalqi, M. A., Alomari, S. A., Jarrah, H. M., & Alotaibi, A. H. (2026). Prevalence and spectrum of coronary artery anomalies detected on coronary CT angiography. International Journal of Cardiology Cardiovascular Risk and Prevention, 29, 200614. https://doi.org/10.1016/j.ijcrp.2026.200614
  11. Taylor, A. J., Cerqueira, M., Hodgson, J. McB., et al. (2010). ACCF/SCCT/ACR/AHA/ASE/ASNC/NASCI/SCAI/SCMR appropriate use criteria for cardiac computed tomography. Journal of the American College of Cardiology, 56(22), 1864-1894. https://doi.org/10.1016/j.jacc.2010.07.005
  12. Ouali, S., Neffeti, E., Sendid, K., Elghoul, K., Remedi, F., & Boughzela, E. (2009). Congenital anomalous aortic origins of the coronary arteries in adults: A Tunisian coronary arteriography study. Archives of Cardiovascular Diseases, 102(3), 201-208. https://doi.org/10.1016/j.acvd.2009.01.001
  13. von Elm, E., Altman, D. G., Egger, M., Pocock, S. J., Gøtzsche, P. C., & Vandenbroucke, J. P. (2007). The Strengthening the Reporting of Observational Studies in Epidemiology (STROBE) statement: Guidelines for reporting observational studies. Lancet, 370(9596), 1453-1457. https://doi.org/10.1016/S0140-6736(07)61602-X
  14. Andishmand, A., Montazerghaem, H., Pedarzadeh, A., Varastehravan, H. R., Mohammadi, H., Nafisi Moghadam, R., et al. (2023). Prevalence and characteristics of coronary artery anomalies (CAAs) in 3016 symptomatic adult participants undergoing coronary computed tomography angiography (CCTA): A single-center retrospective study in Iran. Journal of Cardiovascular and Thoracic Research, 15(4), 218-222. https://doi.org/10.34172/jcvtr.2023.32860
  15. Alshumrani, G. A. (2024). High prevalence of anatomical variations and anomalies of the coronary arteries detected by CT angiography in symptomatic patients. Congenital Heart Disease, 19(2), 197-206. https://doi.org/10.32604/chd.2024.049401
  16. Sidhu, N. S., Wander, G. S., Monga, A., & Kaur, A. (2019). Incidence, characteristics and atherosclerotic involvement of coronary artery anomalies in adult population undergoing catheter coronary angiography. Cardiology Research, 10(6), 358-368. https://doi.org/10.14740/cr941
  17. Li, K., Hu, P., Luo, X., et al. (2024). Anomalous origin of the coronary artery: Prevalence and coronary artery disease in adults undergoing coronary tomographic angiography. BMC Cardiovascular Disorders, 24(1), 271. https://doi.org/10.1186/s12872-024-03942-8
  18. Basso, C., Maron, B. J., Corrado, D., & Thiene, G. (2000). Clinical profile of congenital coronary artery anomalies with origin from the wrong aortic sinus leading to sudden death in young competitive athletes. Journal of the American College of Cardiology, 35(6), 1493-1501. https://doi.org/10.1016/S0735-1097(00)00566-0
  19. Doan, T. T., Wilkes, J. K., Reaves-O'Neal, D. L., et al. (2023). Clinical presentation and medium-term outcomes of children with anomalous aortic origin of the left coronary artery: High-risk features beyond interarterial course. Circulation: Cardiovascular Interventions, 16(5), e012635. https://doi.org/10.1161/CIRCINTERVENTIONS.122.012635
  20. Yousif, N., Shahin, M., Lüscher, T. F., & Obeid, S. (2019). Gender differences in types, frequency, clinical manifestations and atherosclerotic burden of coronary artery anomalies. Reviews on Recent Clinical Trials, 14(1), 41-46. https://doi.org/10.2174/1574887113666180820111341
  21. Akpinar, I., Sayin, M. R., Karabag, T., Gursoy, Y. C., Kucuk, E., Kiran, S., et al. (2013). Differences in sex, angiographic frequency, and parameters in patients with coronary artery anomalies: Single-center screening of 25,368 patients by coronary angiography. Coronary Artery Disease, 24(4), 266-271. https://doi.org/10.1097/MCA.0b013e32835faf43
  22. Möhlenkamp, S., Hort, W., Ge, J., & Erbel, R. (2002). Update on myocardial bridging. Circulation, 106(20), 2616-2622. https://doi.org/10.1161/01.CIR.0000038420.14867.7A
  23. Alegria, J. R., Herrmann, J., Holmes, D. R., Jr., Lerman, A., & Rihal, C. S. (2005). Myocardial bridging. European Heart Journal, 26(12), 1159-1168. https://doi.org/10.1093/eurheartj/ehi203
  24. Devabhaktuni, S., Mercedes, A., Diep, J., & Ahsan, C. (2016). Coronary artery ectasia—A review of current literature. Current Cardiology Reviews, 12(4), 318-323. https://doi.org/10.2174/1573403X12666160504100159
  25. Angelini, P. (2007). Coronary artery anomalies: An entity in search of an identity. Circulation, 115(10), 1296-1305. https://doi.org/10.1161/CIRCULATIONAHA.106.618082
